Standby | kVA | 170 |
Standby | kW | 136 |
Prime | kVA | 150 |
Prime | kW | 120 |
Rated Speed | r.p.m | 1500 |
Power Factor | Cos Phi | 0,8 |
Brand | DOOSAN | |
Model | DP086TA | |
Engine Type | 4 Stroke – Diesel | |
Injection Type | Direct Injection | |
Aspiration Type | Turbo Charged | |
Number of cylinders and arrangement | 6 | |
Bore&Stroke | mm | 111×139 |
Displacement | L | 8 |
Cooling System | Water Cooling | |
Compression Ratio | 16:07 | |
Fuel Consumption Standby | l/h | 37,9 |
Fuel Consumption 100% PRP | l/h | 33,7 |
Fuel Consumption 75 % PRP | l/h | 25,5 |
Fuel Consumption 50 % PRP | l/h | 17,4 |
Total oil capacity including tubes,filters | L | 15,5 |
Total coolant capacity | L | 44 |
Governor | Type | Electronic |
Manufacturer | Gentech / Leroy Somer / Stamford |
LxWxH | mm | 2600x1100x1940 |
Weight | kg | 1983 |
Fuel Tank | lt | 360 |
LxWxH | mm | 3500x1100x2240 |
Weight | kg | 2146 |
Fuel Tank | lt | 360 |
